POF 1x4 Optical Switch
  • POF 1x4 Optical Switch
  • POF 1x4 Optical Switch

POF 1x4 Optical Switch

Switch Type:Mechanical

Package Type:Module

Fiber Configurations:1x4

Channel:4

Product Details

Description

1xN optical switch is a kind of functional component, with the ability of switching optical route. In optical fiber transmission system, it is used for multi-channel fiber monitoring, multi light source / detector selection, and optical fiber path protection etc. Besides, it is also used in optical fiber test system for optical fiber and its component test, outdoor cable test and multi-spot optical sensors monitoring system.



Features
Low Loss and High Reliability
Parallel Interface (TTL)
Modularized Design
Epoxy-free on Optical Path



Applications
Ring Network
Remote Monitoring in Optical Network
Testing of Fiber, Optical Component



Specifications

Parameters

Unit

SUN-FSW-1×4

Channel Number

-

N=4

Wavelength Range

nm

800 ~ 1600

Test Wavelength

nm

850 or 1300 or 1550

Fiber type

-

400 um core diameter, POF( Customer supply )

Insertion Loss 1, 2

dB

Typ: 2.5       Max: 3.0

Crosstalk 1

dB

≥ 55

Repeatability

dB

≤ ±0.05

Durability

Cycles

≥ 10 Million

Switching Time

ms

20 ms for adjacent channels

Operating Temperature

-20 ~ +70

Storage Temperature

-40 ~ +85

Relative Humidity

%

5 ~ 95

Dimension

mm

185×78×45

Control Interface

-

Parallel port or UART or RS232

Note:

1    Within operating temperature and SOP.

2    Including Connectors.

Optical Route

Ordering Informations

SUN-FSW-1×4-A-B-C-D-E-F-G

4

A

B

C

D

E

F

G

Channel

Fiber Type

Test

Wavelength

Tube Type

Fiber Length (Include

connector)

Connector

Dimension

Control

Interface

4

POF:

400 um core

diameter,

POF (Customer Supply)

850: 850nm

1300:1300nm

1550: 1550nm

X: other

30: 3mm

X: other

05: 0.5±0.05m

10: 1.0±0.05m

X: other

SMA: SMA

NA: None

X: other

184×78×45-DB9-F

P: Parallel port

U: UART

R: RS232
