Switch Type：MEMS
Package Type：Module
Fiber Configuration：MCS
Wavelength Range：1527nm; 1568nm
Dimension：220(L) x120(W) x15(H) ±0.2mm
Multicast Switch (MCS) series are designed for next generation of CDC-ROADM system based on PLC splitter and optical switch technology. The product is an integrated module containing MxN type MCS and electronic control unit inside. The module could implement any optical input can be routed to any of the out ports function. It could be used at key locations in the CDC-ROADM optical network.
Features
· ADD & DROP in one module
· Hitless switching
· Low insert loss
· Low power dissipation
Applications
· DWDM Networks
· ROADM Systems
|
Parameters |
Units |
Specification |
|||
|
Min. |
Typ. |
Max. |
|||
|
Operation Wavelength Range |
nm |
1260 |
|
1650 |
|
|
Test Wavelength |
nm |
1310 or 1550 or 1610 |
|||
|
Insertion Loss 1,2 |
2x4 / D2x4 |
dB |
|
|
8.6 |
|
4x4 / D4x4 |
|
|
8.6 |
||
|
4x8 |
|
|
11.8 |
||
|
8x8 |
|
|
11.8 |
||
|
Insertion Loss Uniformity |
dB |
|
|
1.5 |
|
|
Polarization Dependent Loss |
dB |
|
|
0.5 |
|
|
Wavelength Dependent Loss 3 |
dB |
|
|
0.3 |
|
|
Polarization Mode Dispersion |
ps |
|
|
0.5 |
|
|
Block State Insertion Loss |
dB |
40 |
|
|
|
|
Return Loss 2 |
dB |
45 |
|
|
|
|
Port Isolation |
dB |
40 |
|
|
|
|
Port Switch Time |
ms |
|
|
10 |
|
|
Repeatability |
dB |
|
±0.05 |
|
|
|
Maximum Optical Input Power |
dBm |
|
|
27 |
|
|
Optical Detection Range(IN,OUT) |
dBm |
-35 |
|
27 |
|
|
Detection Accuracy |
dB |
|
0.5 |
|
|
|
Durability |
Cycles |
109 |
|
|
|
|
Power Consumption |
W |
|
|
15 |
|
|
Operating Temperature |
℃ |
-40~+70 |
|||
|
Storage Temperature |
℃ |
-40~+85 |
|||
|
Dimension |
mm |
125(L) x80(W) x20(H) ±0.2 |
|||
|
Note: 1 Within operating temperature and SOP，MM CPR＞16. 2 Excluding connectors. 3 Power off isolation same as cross-talk. 4 WDL is specified in a ±20 nm of 1310nm or ±20 nm of 1550nm,at 23°C. 5 Repeatability is defined after 100 cycles. |
|||||
.png)
SUN-MCS-N-A-B-C-D-E-F
|
N |
A |
B |
C |
D |
E |
F |
|
Module Type |
Fiber Type |
Test Wavelength |
Tube Type |
Fiber Length (Include connector) |
Connector |
Communication Interface type |
|
2x4: 2 in-4 out D2x4: Double 2 in-4 out 4x4: 4 in-4 out D4x4: Double 4 in-4 out 4X8: 4 in-8 out 8X8: 8 in-8 out
|
SM: SM,9/125 X: Others |
1310: 1310nm 1550: 1550nm 1516: 1550/1610nm X: Others |
90:900um X: Others |
05: 0.5m±5cm 10: 1.0m±5cm 15: 1.5m±5cm X: Others |
OO: None FP: FC/PC FA: FC/APC SP: SC/PC SA: SC/APC LP: LC/PC LA: LC/APC X: Others |
C: I2C U: UART |
